VOITA 12v 24v to 5v 5A DC-DC Converter 12v 24v to 5v Buck Converter Step Down Converter

1 / 5

VOITA 12v 24v to 5v 5A DC-DC Converter 12v 24v to 5v Buck Converter Step Down Converter

Send Inquiry

Product Description

Feature

Synchronous rectification technology, imported components, conversion efficiency more than 96%
Imported internal resistance capacitor filter, withstand high temperature.
Flame retardant plastic shell, Almost no heat generated when using
Chip smart protection, anti-overheating, overcurrent protection

Specification

Category	Parameter	Details
Model	VT-DD122455
Input	Rated voltage	DC 12V
	Voltage range	10-35V
	Efficiency	96% @ 12V input
	Cables	Positive (red) / Negative (black) 18 AWG @ 15cm length
Output	Voltage	5V
	Max. rated current	5A
	Max. rated power	25W
	Cables	Positive (yellow) / Negative (black) 18 AWG @ 15cm length
Environment	Working temperature	-25°C ~ 80°C
Environment	Storage temperature	-25°C ~ 80°C
Function	Short circuit protection	YES
	Over current protection	YES
	Waterproof	IP67
	Over temperature protection	YES
	Over voltage protection	YES
Mechanical	Weight	65g
Mechanical	Size	463218mm

Product Details

Frequently Asked Questions

Q1: What is the input voltage range for this step-down converter?

A1: The converter is rated for a DC 12V input but operates over a wide input voltage range of 10V to 35V, allowing for stable power conversion even with fluctuating input supplies.

Q2: What is the maximum conversion efficiency of this module?

A2: Thanks to advanced synchronous rectification technology and high-quality imported components, the converter achieves a maximum conversion efficiency of over 96% at 12V input.

Q3: Is this product waterproof and suitable for outdoor use?

A3: Yes, this converter has an IP67 waterproof rating. It is encased in a flame-retardant plastic shell and is highly dust and water-resistant, making it suitable for demanding environments.

Q4: What protective features are built into the device?

A4: The module is equipped with a smart protection chip that offers built-in short circuit protection, overcurrent protection, overvoltage protection, and over-temperature protection.

Q5: What are the wire specifications for the input and output lines?

A5: Both the input and output lines use 18 AWG wires that are 15cm in length. The input uses Red (positive) and Black (negative) wires, while the output uses Yellow (positive) and Black (negative) wires.

Q6: What is the working temperature range for this converter?

A6: The converter is designed to operate reliably in harsh conditions with a working temperature range of -25°C to 80°C and a storage temperature range of -25°C to 80°C.
