Wholesale DC to DC Power Converter 12V 24V 28V Battery Charger for 24V LiFePO4 Batteries and Battery Banks Factory Direct Price

Core Features

DC-DC non-isolated power module
100% full power with high stability output
IP68 Rated: Dustproof, moistureproof, and shockproof
Flexible Input: Compatible with DC (11-16V), 12V batteries, and generators
Intelligent Charging: Automatic constant voltage at 29.2V as battery capacity increases

Technical Specifications

Model	VT-DD122820C
Input Voltage	Any voltage between (11-16)V
Output Current	20A
Output Voltage	28V
Operating Temperature	-35°C to +80°C
Output Power	560W
Under-voltage Protection	13.5V to start, 13V to shut down
Dimensions	10011335mm
Battery Charge Type	24V LiFePO4 batteries / battery bank

Frequently Asked Questions

Is this module suitable for outdoor use?

Yes, the module is IP68 rated, meaning it is completely dustproof and can withstand immersion in water, making it ideal for harsh outdoor environments.

What type of batteries can I charge with this device?

This specific model is designed for 24V LiFePO4 batteries or battery banks. It ensures a stable 29.2V constant voltage during the final charging stage.

Does the module have low-voltage protection?

Yes, it features under-voltage protection. It will start operating at 13.5V and automatically shut down at 13V to protect the input source.

What is the operating temperature range?

The module is built to perform in extreme conditions, with an operating temperature range from -35°C to +80°C.

Is this an isolated or non-isolated module?

This is a DC-DC non-isolated power module, offering high efficiency and 100% full power output in a compact design.

Can it be connected directly to a vehicle generator?

Absolutely. It can be connected to any DC source between 11V and 16V, including 12V vehicle batteries and alternators/generators.

Product Detail

Factory Price Power Converter Dc to Dc 12 24v 28v Battery Charger for 24v LiFePO4 Batteries/ Battery Bank

Product Description
