VOITA 12V to 56V 10A DC Step Up Converter for CVCC DC Charger High Efficiency Power Supply Solution for Global B2B Buyers

Key Features

⚡

High Efficiency: Synchronous rectification technology with imported components, providing conversion efficiency over 96%.

🌡️

Durable Build: Imported internal resistance capacitor filter, specifically designed to withstand high temperatures.

💧

Waterproof: Organic silicone packaging technology allows the unit to work even when directly soaked in water (IP67).

🛡️

Smart Protection: Integrated chip for anti-overheating, over-current, over-voltage, and short-circuit protection.

🏗️

Robust Shell: Aluminum alloy enclosure provides anti-shock, anti-drop, anti-moisture, and anti-dust capabilities.

Technical Specifications

Model	VT-DD12565C
Input	Rated voltage	DC 12V
	Voltage range	9-16V
	Efficiency	96% @ 12V input
Output	Voltage	56V
	Max. rated current	10A
	Max. rated power	560W
	Voltage regulation	±1%
	Load regulation	2%
Environment	Working temperature	-20℃ ~ 85℃
	Working humidity	10% ~ 90%RH
	Storage temperature	-20℃ ~ 85℃
Function	Short circuit protection	YES
	Over current protection	YES
	Waterproof	IP67
	Over temperature protection	YES
	Over voltage protection	YES
Mechanical	Weight	2.6kg
Mechanical	Size	22013050MM

Product Gallery

Certifications & Dimensions

Please visit our website and submit your inquiry to learn more about our capabilities. If you cannot find a product that meets your specifications, please contact us immediately! Consulting us is completely free, but it could be the start of a successful collaboration! Our professional team will respond to your inquiry within one hour. We are a leading one-stop power solution provider, specializing in power products and customized power services.

Frequently Asked Questions

What is the maximum efficiency of this DC-DC converter?

The unit utilizes synchronous rectification technology and high-quality imported components to achieve a conversion efficiency of over 96%.

Is the device waterproof and suitable for outdoor use?

Yes, it features an IP67 rating thanks to organic silicone packaging technology, making it resistant to water, dust, and moisture.

What safety protections are built into the product?

The converter includes comprehensive smart protection for short circuits, over-current, over-voltage, and over-temperature.

What is the supported input voltage range?

The rated input is DC 12V, but it can safely operate within a wider range of 9V to 16V DC.

Can the converter operate in extreme temperatures?

Yes, the unit is designed to work in environment temperatures ranging from -20°C up to 85°C.

What material is used for the outer casing?

It uses a high-grade aluminum alloy shell which provides excellent anti-shock and anti-drop durability while assisting in heat dissipation.
