Lead Acid 36 48 Volt Golf Cart Battery Charger with 36v 5a 48volt 4a Club Golf Car Battery Charger for Yamaha EZGO CARGO

1 / 5

Lead Acid 36 48 Volt Golf Cart Battery Charger with 36v 5a 48volt 4a Club Golf Car Battery Charger for Yamaha EZGO CARGO

Send Inquiry

Product Description

⚙️ Features

▶

4-Stage Charging Mode: Includes pre-charging, constant current charging (Bulk), constant voltage charging (ABS), and floating charging for optimal battery health.

▶

Comprehensive Protection: Equipped with overheating protection, working current reduction protection, short circuit protection, and reverse connection protection.

▶

Smart Fan Control: Automatically detects charging current and charger temperature to adjust fan speed for efficiency and noise control.

▶

Lithium Battery 0V Activation: When a lithium battery is in low voltage protection (UVP) state, the charger can automatically activate charging.

▶

0℃ Charging Function: Selectable lithium battery 0℃ charging function via DIP switch for cold environment performance.

📊 Technical Datasheet

Model	AC1230 Pro	AC2415 Pro	AC4810 Pro
Input voltage & frequency	180V-260VAC \| 50HZ
Efficiency	>90%
Battery voltage	12V	24V	48V
Max output (Normal)	30A	15A	10A
Max output (Low Current)	15A	7.5A	5A
Max output (Night Mode)	10A	6A	3A
Rec. Battery Capacity (Max)	300AH	150AH	100AH
Rec. Battery Capacity (Min)	100AH	50AH	30AH
DC Power Supply (Default)	12.6V/30A	25.2V/15A	50.4V/10A
DC Power Supply (APP Range)	12V-13.8V	24V-27.6V	48V-55.2V
Temp Compensation	18mV/℃	36mV/℃	72mV/℃
Charge Algorithm	4-stage adaptive
Protection	Reverse polarity (fuse), output short circuit, over temperature
Operating Temp	-20 to +50 ° C
Material & Colour	Aluminium, Iron grey
Dimensions	221×155×70mm

🖼️ Product Showcase

🛠️ Customization Options

About the adjustable DC regulated power supply, we can customize different kinds of specifications according to your request:

(1) Input voltage: 1 phase 110VAC/220Vac or 3 phases 380Vac;
(2) Output voltage: 0-3000V variable or appointed;
(3) Output current: 0-2000A variable or appointed.
(4) Serial port: RS232, RS485, timing switch.

🔍 Internal Structure & Quality

❓ Frequently Asked Questions

1. What are the benefits of the 4-stage charging mode?

The 4-stage adaptive algorithm (Pre-charge, Bulk, ABS, and Float) ensures that the battery is charged efficiently while preventing overcharging, which significantly extends the overall lifespan of the battery.

2. Can this charger recover a lithium battery in UVP state?

Yes, the charger features a lithium battery 0V automatic activation function. It can detect and reactivate lithium batteries that have entered Under Voltage Protection (UVP) mode.

3. How does the quiet mode/night mode work?

Night mode reduces the maximum output current (e.g., to 10A for the 12V model), which lowers heat generation and allows the fan to operate at much quieter speeds for noise-sensitive environments.

4. Is the charger safe for permanent connection?

Absolutely. With built-in protections for overheating, short circuits, and reverse polarity, along with the floating charge stage, it is designed for safe, long-term battery maintenance.

5. Can I use this charger in cold climates?

Yes, the device is rated for operating temperatures as low as -20°C. Additionally, it includes a specific DIP switch setting to enable lithium battery charging at 0°C.

6. What battery types are compatible with this charger?

This charger is versatile and compatible with standard lead-acid batteries (with temperature compensation) as well as lithium battery systems, with adjustable parameters via the dedicated APP.
