| Model | QA600A |
| AC Input Voltage Range | 110V/220VAC; 45-65Hz |
| AC Input Max Current | 11.5A@220VAC; 23A@110VAC |
| Efficiency | ≥93.0% |
| Noise | ≤45dB |
| Protection level | IP65 |
| Output Voltage & Current | 48V 10A |
| Safety | Active LLC technique is applied for a rapid respond on a fault; Quick active software self-protection and reliable passive hardware self-protection on VOLTAGE&CURRENT; Advanced charging strategy is integrated as a safeguard for battery system. |
| Reliability | The shell is shaped by integrated die casting technique and filled with special glue. The active cooling fan is also designed to be a fan with a potting structure and a longer life. Products have been operating in all kinds of industrial environment (Wet, Hot, Cold, High altitude) for more than ten years. |
| Functions |
• CAN BUS Interface • Triple Colors Indicator • Charging Interlock System • Auxiliary power supply 12V |
| Operating Temperature | -30℃ ~ 65℃ |
| Size & Weight | 199*122.5*77mm | 1.9 kg |
| Protection Functions |
Burnout Protection: Charger lowers power or goes to standby if temperature exceeds limitations. Reverse Connection: Shuts down automatically if batteries are connected reversely. No-load Protection: No output when batteries are not connected. Short Circuit Protection: Shuts down upon short circuit; requires troubleshooting to restart. Automatic Shutdown: Turns off automatically when fully charged. |
