| Model | VT-ADP6005 |
| Input Voltage Range |
1 Phase: AC110V ± 10%, 50Hz/60Hz; 1 Phase: AC220V ± 10%, 50Hz/60Hz; 3 Phase: AC380V ± 10%, 50Hz/60Hz; |
| Output voltage | 0-600VDC |
| Output current | 0-5A |
| Power | 3000W |
| Voltage Stabilization | ≤0.3% + 10mV |
| Load Stabilization | ≤0.5% + 30mV |
| Ripples and Noises | ≤0.5% + 10mVrms |
| Voltage Display Accuracy |
4-digit Accuracy: ±1% + 1 word (10%-100% rating) Range: 0.000V-9.999V, 0.00V-99.99V, 0.0V-999.9V |
| Current Display Accuracy |
4-digit Accuracy: ±1% + 1 word (10%-100% rating) Range: 0.000A-9.999A, 0.00A-99.99A, 0.0A-999.9A |
| Insulation resistance |
Input-output: ≥ 20MΩ Input-shell: ≥ 20MΩ Output-shell: ≥ 80MΩ |
| Insulation strength |
Input-output: AC1500V, 10mA, 1 minute Input-shell: AC1500V, 10mA, 1 minute Output-shell: AC1500V, 10mA, 1 minute |
| Output OverVoltage Protection | Built-in O.V.P. protection, protection limited value is rated +5% |
| Output Over Load Protection | Overload, current limit, constant current output |
| OverTemperature Protection | Built-in O.T.P. protection, protection value: 85℃ ± 5% heat sink temperature |
| Voltage Setting | 10-turn precision potentiometer |
| Current Setting | 10-turn precision potentiometer |
| Output Polarity | Output Positive(+) negative(-) Can be grounded at will |
| Heat Dissipation Way | Forced fan cooling |
| Work Conditions | Indoor use design, Temperature: 0℃ ~ 40℃; Humidity: 10% ~ 85%RH |
| Storage Conditions | Temperature: -20℃ ~ 70℃; Humidity: 10% ~ 90%RH |
| Product Dimension | 220*460*170mm |
| Analog Remote Control Function (Optional) | |
|---|---|
| Remote Control Function Details |
• 0-5V / 0-10Vdc analog signal control output voltage/current • 0-5V / 0-10Vdc analog signal to read-back output voltage current • 0-5V / 0-10Vdc analog Switch signal to control output • 4-20mA analog signal control output voltage & current • RS232 / RS485 Communication port control by computer |
We can customize specifications for adjustable DC regulated power supplies according to your request:
