| Model | VT-ADP20060 |
| Input Voltage Range | 1 Phase: AC110V±10%, 50Hz/60Hz; 1 Phase: AC220V±10%, 50Hz/60Hz; 3 Phase: AC380V±10%, 50Hz/60Hz; |
| Output Voltage | 0-200VDC |
| Output Current | 0-60A |
| Power | 12000W |
| Voltage Stabilization | ≤0.3%+10mV |
| Load Stabilization | ≤0.5%+30mV |
| Ripples and Noises | ≤0.5%+10mVrms |
| Voltage Display Accuracy | 4-digit Accuracy: ±1%+1 word (10%-100% rating) 0.000V-9.999V, 0.00V-99.99V, 0.0V-999.9V |
| Current Display Accuracy | 4-digit Accuracy: ±1%+1 word (10%-100% rating) 0.000A-9.999A, 0.00A-99.99A, 0.0A-999.9A |
| Insulation Resistance | Input-output: ≥ 20m Ω; Input-shell: ≥ 20m Ω; Output-shell: ≥ 80m Ω |
| Insulation Strength | Input-output: AC1500V, 10mA, 1min; Input-shell: AC1500V, 10mA, 1min; Output-shell: AC1500V, 10mA, 1min |
| Protection | Output O.V.P (Rated +5%); Output Overload (Current limit, constant current); O.T.P (85℃±5% heat sink) |
| Settings | 10-turn precision potentiometer for both Voltage and Current |
| Environmental Conditions | Working: 0℃~40℃, 10%~85%RH; Storage: -20℃~70℃, 10%~90%RH |
| Product Dimension | 483*575*135mm |
Customize Range about DC Adjustable Power Supply
Regarding the adjustable dc regulated power supply, we can customize different kinds of specifications according to your request, such as:
