Please Note: This price is based on 220VAC single phase input. Please contact us if you need 110VAC or 380VAC input. We also can customize!
Key Features
- ✓Small size and light weight, suitable for working table and rack installation.
- ✓Use PWM modulation, crystal module consumption of low power, high efficiency, more power saving.
- ✓Carefully designed electronic technology circuit, forced air cooling heat treatment, with a very low temperature coefficient.
- ✓Low noise and low ripple.
- ✓High gain amplifier circuit design, with good rapid response characteristics.
- ✓Voltage and current digital display meter with 4-bit high sampling rate and high resolution.
- ✓Built-in O.V.P over voltage protection and O.T.P over temperature protection; perfect and reliable protection functions.
- ✓Designed with load terminal voltage detection for accurate reading and control.
Technical Datasheet
| Specification |
Details |
| Model |
VT-ADP10200 |
| Input Voltage Range |
1 Phase: AC110V/AC220V±10%; 3 Phase: AC380V±10% (50Hz/60Hz) |
| Output Voltage |
0-10VDC |
| Output Current |
0-200A |
| Power |
2000W |
| Voltage Stabilization |
≤0.3%+10mV |
| Load Stabilization |
≤0.5%+30mV |
| Ripples and Noises |
≤0.5%+10mVrms |
| Display Accuracy |
4-digit Accuracy: ±1%+1 word |
| Insulation Strength |
Input-Output/Shell: AC1500V, 10mA, 1 minute |
| Protection |
O.V.P (Rated +5%), Overload current limit, O.T.P (85°C±5%) |
| Dimension |
150*350*160mm |
Optional Remote Control Functions
- ▶0-5V / 0-10Vdc analog signal control output
- ▶0-5V / 0-10Vdc analog signal for read-back
- ▶4-20mA analog signal control
- ▶RS232/RS485 Communication port for computer control
Customization Range
Regarding adjustable DC regulated power supplies, we can customize various specifications according to your request:
- ⚡Input Voltage: 1 phase 110VAC/220VAC or 3 phases 380VAC
- ⚡Output Voltage: 0-3000V variable or fixed
- ⚡Output Current: 0-2000A variable or fixed
- ⚡Ports: RS232, RS485, timing switch
Frequently Asked Questions
1. How long is the delivery time?
Regular order delivery time is 3-7 days after the order (PI) is paid.
2. What are your payment terms?
We accept TT, PAYPAL, and Western Union.
3. Can I order a sample before a bulk order?
Yes, sample orders are fully supported.
4. What shipping methods do you provide?
We provide shipping via DHL, FEDEX, UPS, TNT, and China Post.
5. What is the warranty on your products?
All products come with a 1-2 year warranty.
6. What types of power products are available?
Our manufacturing range includes Power Adapters, DC-DC Converters, DC-AC Inverters, DC Power Supplies, Battery Chargers, and Telecom Rectifiers.
