⚡ Technical Specifications
| Model |
VT-300Z |
VT-600Z |
VT-1000W |
VT-1500W |
| Output power |
300W |
600W |
1000W |
1500W |
| Display method |
LED Display |
LCD Display |
LCD Display |
LCD Display |
| Input voltage |
12V/24V/48V/60V/72Vdc |
| Input range |
12Vdc(10-15), 24Vdc(20-30), 48Vdc(40-60), 60Vdc(50-75), 72Vdc(60-90) |
| Low voltage protection |
12V(10.0V±0.3), 24V(20.0V±0.3), 48V(40.0V±0.3), 60V(50.0V±0.3), 72V(60.0V±0.3) |
| Overvoltage protection |
12V(15.0V±0.3), 24V(30.0V±0.3), 48V(60.0V±0.3), 60V(75.0V±0.3), 72V(90.0V±0.3) |
| Recovery voltage |
12V(13.2V±0.3), 24V(25.5V±0.3), 48V(51.0V±0.3), 60V(65.0V±0.3), 72V(78.0V±0.3) |
| No-load current |
0.35A |
0.4A |
0.6A |
0.7A |
| Overload protection |
300W ＞ 110% |
600W ＞ 110% |
1000W ＞ 110% |
1500W ＞ 110% |
| Output voltage |
110V/220Vac |
| Output frequency |
50Hz/60Hz |
| Output waveform |
Pure sine wave |
| Overheating protection |
80°±5° |
| Waveform THD |
≤3% |
| Conversion efficiency |
90% |
| Cooling method |
Fan cooling |
| Dimensions |
183*110*60mm |
228*173*76mm |
310*173*76mm |
360*173*76mm |
| Product weight |
1kg |
2kg |
3kg |
3.6kg |
💎 Core Features
01
The inverter power supply adopts SPWM technology controlled by MCU micro-processing, pure sine wave output, and the waveform is pure.
02
The unique dynamic current loop control technology ensures reliable operation of the inverter.
03
High load adaptability, compatible with inductive, capacitive, resistive, and mixed loads.
04
Heavy load capacity and superior impact resistance for demanding equipment.
05
Comprehensive protection: input overvoltage/undervoltage, overload, overheat, and output short circuit protection.
06
Intuitive LCD crystal display allows for real-time monitoring of operational status.
07
Stable performance, safe and reliable design with a long-lasting service life.
🔍 Product Details
🛠️ Quality & Professionalism
Frequently Asked Questions
What is the advantage of a Pure Sine Wave inverter?
Pure sine wave inverters provide high-quality electricity, similar to the utility grid. They are essential for sensitive electronics, ensure motors run cooler and quieter, and prevent interference in audio/video equipment.
How does the overheating protection work?
The inverter is equipped with intelligent sensors. If the internal temperature reaches 80°±5°, the system will automatically trigger protection protocols to prevent damage to the circuitry.
Can these inverters handle inductive loads?
Yes, thanks to the SPWM technology and robust MCU control, these inverters have excellent load adaptability and can handle inductive loads like refrigerators, pumps, and power tools.
What does the LCD display show?
The LCD display provides real-time information on the operational status, including input/output voltage levels and current protection states, making it easy to monitor performance.
What is the conversion efficiency of these models?
These inverters are highly efficient, with a conversion rate of up to 90%, minimizing energy loss during the DC to AC transformation process.
How is the cooling managed during heavy usage?
The system utilizes a forced air cooling method with integrated fans that activate based on load and temperature requirements to maintain optimal operating conditions.
