12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
1 / 5
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter
12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter

12V 24V Dc Invert Ac 220V Pure Sine Wave Inverter 1000W peak Power Solar Inverter

Send Inquiry

Product Description

1000W Pure Sine Wave Inverter
1000W Pure Sine Wave Inverter
Key Features
🛡️
The inverter power supply adopts SPWM technology controlled by MCU micro-processing, pure sine wave output, and the waveform is pure.
⚡
The unique dynamic current loop control technology ensures reliable operation of the inverter.
📊
The sine wave inverter adopts LCD liquid crystal display mode, and the state is clear at a glance.
🏗️
Heavy load capacity and impact resistance.
🔒
It has perfect protection functions such as input overvoltage, undervoltage, overload, overheat, and output short circuit.
⚙️
Load adaptability, including inductive load, capacitive load, resistive load, mixed load.
💎
Stable performance, safe and reliable, long service life.
Technical Parameters
ModelVT-1000W
Continuous Power500W
Peak Power1000W
Display methodLCD
Input voltage12V/24V/48V/60Vdc
Input range12Vdc(9.5-15.8); 24Vdc(19.5-30); 48Vdc(39-60); 60Vdc(53-72.5)
Low voltage protection12Vdc(≤9.5); 24Vdc(≤19.5); 48Vdc(≤39); 60Vdc(≤53)
Over voltage protection12Vdc(≥15.8); 24Vdc(≥30); 48Vdc(≥60); 60Vdc(≥72.5)
Low voltage alarm12Vdc(10.2±0.5V); 24Vdc(21±0.5V); 48Vdc(43.2±0.5V); 60Vdc(54±0.5V)
Over heat protection>60℃
Protection functionShort circuit, Reverse connection, Battery low voltage, Battery low pressure alarm, Battery high voltage, Overload, Over temperature
Output voltage220Vac±6V
Output frequency50Hz
Output waveformPure sine wave
Conversion efficiency90%
Cooling methodFan cooling
Dimensions210*103*60mm
Net weight0.8kg
Product Gallery
Detailed Applications
Frequently Asked Questions
1. What is the difference between a pure sine wave and a modified sine wave?
A pure sine wave inverter provides a clean and stable power output identical to the electricity from your wall outlet. It is safer for sensitive electronics and appliances with motors, ensuring they run cooler, quieter, and more efficiently.
2. How do I choose the right input voltage (12V/24V/48V/60V)?
The inverter's input voltage must match your battery system's voltage. For example, if you are using a 12V car battery, you must choose the 12Vdc model. Choosing the wrong voltage will result in the unit not functioning or potential damage.
3. What can I power with a 1000W peak / 500W continuous inverter?
This unit is ideal for powering laptops, LED lights, small fans, mobile chargers, and other small household electronics that consume less than 500W continuously. Always check the power rating of your device before connecting.
4. Does this inverter have an automatic shut-off feature?
Yes, it features comprehensive protection functions. It will automatically shut down or alarm in cases of overvoltage, low voltage, overload, overheating, or short circuits to protect both the inverter and your connected devices.
5. Is the cooling fan always running?
The cooling fan is designed to manage the internal temperature efficiently. It typically activates based on the load and temperature to ensure the device maintains stable performance and a long service life.
6. What is the efficiency of the power conversion?
This inverter offers a high conversion efficiency of approximately 90%, meaning more of your battery power is effectively converted into usable AC power with minimal energy loss.
