Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
1 / 5
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v
Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v

Wholesale 3000W 4000W DC 12V 24V to AC 110V 220VAC Car Inverter 12v 220v

Send Inquiry

Product Description

Key Features
✓
The inverter power supply adopts SPWM technology controlled by MCU micro-processing, pure sine wave output, and the waveform is pure.
✓
The unique dynamic current loop control technology ensures reliable operation of the inverter.
✓
High load adaptability, compatible with inductive, capacitive, resistive, and mixed loads.
✓
Heavy load capacity and superior impact resistance for demanding equipment.
✓
Comprehensive protection functions: input overvoltage, undervoltage, overload, overheat, and output short circuit protection.
✓
LCD liquid crystal display mode provides clear real-time status at a glance.
✓
Stable performance, safe and reliable design with a long service life.
Technical Specifications
Model VT-2000Z VT-3000Z VT-4000W VT-5000W
Output power 2000W 3000W 4000W 5000W
Display method LCD Display LCD Display LCD Display LCD Display
Input voltage 12V/24V/48V/60V/72Vdc
Input range 12Vdc(10-15), 24Vdc(20-30), 48Vdc(40-60), 60Vdc(50-75), 72Vdc(60-90)
Low voltage protection 12V(10.0V±0.3), 24V(20.0V±0.3), 48V(40.0V±0.3), 60V(50.0V±0.3), 72V(60.0V±0.3)
Overvoltage protection 12V(15.0V±0.3), 24V(30.0V±0.3), 48V(60.0V±0.3), 60V(75.0V±0.3), 72V(90.0V±0.3)
Recovery voltage 12V(13.2V±0.3), 24V(25.5V±0.3), 48V(51.0V±0.3), 60V(65.0V±0.3), 72V(78.0V±0.3)
No-load current 0.8A 1A 1A 1A
Overload protection 2000W > 110% 3000W > 110% 4000W > 110% 5000W > 110%
Output voltage 110V/220Vac
Output frequency 50Hz/60Hz
Output waveform Pure sine wave
Overheating protection 80°±5°
Waveform THD ≤3%
Conversion efficiency 90%
Cooling method Fan cooling
Dimensions 360*173*76mm 400*242*88mm 400*242*88mm 420*242*88mm
Product weight 4kg 8kg 8.5kg 9kg
Product Gallery
Frequently Asked Questions
What is the advantage of a Pure Sine Wave Inverter?
Pure sine wave inverters provide high-quality electricity similar to grid power. It is ideal for sensitive electronics and prevents noise in audio/video equipment while ensuring appliances run cooler and more efficiently.
Can this inverter handle inductive loads?
Yes, thanks to the SPWM technology and dynamic current loop control, this inverter is fully compatible with inductive loads such as motors, compressors, and power tools.
How do the protection functions work?
The system includes multiple safety layers. If the input voltage is too high or low, or if the unit exceeds safe temperatures or load limits, it will automatically shut down to prevent damage and display the status on the LCD.
What information does the LCD screen display?
The LCD provides real-time data on input voltage, output voltage, frequency, and current status, allowing for easy monitoring of the power supply performance.
What is the conversion efficiency of these models?
These inverters are highly efficient, with a conversion rate of approximately 90%, minimizing energy loss during the DC to AC transformation process.
Is the cooling fan always running?
The inverter utilizes an intelligent fan cooling system designed to maintain optimal operating temperatures, ensuring stability and extending the service life of the internal components.
