Factory Outlet Costomzable Rack Mount Rectifier Systems 220VAC 110VDC 20A 2200W Ac to Dc Rectifier for the Power Systems

Send Inquiry

Product Description

⭐ Key Features

✓ 1. Widely operating range of AC input voltage: 90~290VAC
✓ 2. Compact 19' inch rack mount shelf
✓ 3. Real-time detection of operating status, sound-light alarm
✓ 4. Perfect battery management, accessory battery temperature detector
✓ 5. 20 amp output per module, 60 amp system capacity max for 2U (Whole system 180 amp max)

📊 Specification

Model	VT-R11020
Input Voltage Range	90~290Vac (derate≤176Vac)
Input Frequency	50/60HZ
Power Factor	>0.99
Output Voltage	24VDC
Output Voltage Range	99-143VDC
Output Current Range	20A
Output Efficiency	93.20%
Regulation	±2%
Load Regulation	±2%
Line Regulation	±1
Leakage Current	≤10mA
Work Temperature	-40~55°C
Storage Temperature	-40~70°C
Cooling Method	Forced cooling, front-in & rear-out, the fan is located inside the front panel, with programmable speed by the temperature.
Ingress Protection	The unit can operate when the diameter of dust particle is more than 5µm, with density ≤3*104 /m3. The dust shall not be conducting, electromagnetic or corrosive.

📷 Product Details

📦 Packing & Delivery

🏭 Production Facility

❓ Frequently Asked Questions

Q1: What is the input voltage range for this rectifier system? A: The system supports a wide AC input voltage range from 90V to 290VAC, with derating applicable below 176VAC.

Q2: Can this unit be installed in a standard server rack? A: Yes, it features a compact design suitable for a standard 19-inch rack mount shelf, specifically taking up 2U of space.

Q3: What is the maximum output capacity of the whole system? A: Each module provides a 20 amp output. The 2U system can reach a 60 amp capacity, and the whole system can support up to 180 amp max.

Q4: How does the cooling system operate? A: It uses a forced cooling method (front-in & rear-out) with internal fans. The fan speed is automatically regulated based on the operating temperature.

Q5: Does the system include battery management? A: Yes, it features perfect battery management and includes an accessory battery temperature detector for enhanced safety and longevity.

Q6: Is the device protected against harsh environments? A: The unit is designed to operate in environments with dust particles as long as they are non-conducting, non-electromagnetic, and non-corrosive.
