VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
1 / 5
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter
VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter

VOITA Factory Price AC Bypass Inverter 2kva 48v Rackmount to 220VAC True Sine Wave 2KVA 1600W Inverter

Send Inquiry

Product Description

Inverter Overview
📊 Specification & Description
Description
  • True sine wave output (T.H.D < 3%)
  • Large 128*64 digital LCD display data information & 4 LED display working indicators
  • Standard 19” Rack mount case design
  • 5 Routes Dry contact for system (DC input fault, AC input fault, overload information, by-pass information and output fault)
Function
  • RS232 and RS485 & Optional SNMP communication Port
  • Power-on self-test, Soft output start
  • Audible and visual alarm systems
  • Record historical alarm messages for query
  • Real-time monitoring of system operating status
Key Features
  • Auto switch function: DC to AC, AC bypass, switching time less than 5ms
  • By-pass AC 220V input filtering
  • Start auto restart while AC or DC is recovering
  • Automatic start temperature control fan for cooling
  • Built-in voltage regulator to stabilize AC voltage
  • Comprehensive Protection: Short load, over load, battery over/under voltage, over current, and over temperature
  • Unattended operation: system switches automatically between DC and AC input to provide continuous power
📋 Technical Datasheet
Model VT-HF48S220-2KVA
DC INPUT Rated Voltage: 48V Rated Current: 42A Range: 40-60V
AC Bypass Voltage Range: 170V-270V Rated Current: 9.1A / 13.6A
AC Output Capacity: 2KVA / 1600W Voltage: 220Vac Frequency: 50Hz/60Hz
Performance Waveform: Pure Sine Wave THD: ≤3% Efficiency: ≥85%
Transfer Time Inverter ↔ Bypass: ≤8ms (Switch: <5ms)
Environment Temp: -20℃~+50℃ Humidity: 0~90% Noise: ≤55dB
Dimensions Size: 482*347*88MM Net Weight: 9.00KG Gross Weight: 11.00KG
Protection Input under/over Voltage, Output Over load, Short circuit, Over temperature
🖼️ Product Gallery
⚙️ Technical Details & Interface
❓ Frequently Asked Questions
What is a Pure Sine Wave Inverter and why is it important?
A pure sine wave inverter produces power that is identical to or even better than the power supplied by the utility grid. It is crucial for sensitive electronic equipment, ensuring they run cooler, quieter, and more efficiently without the risk of damage.
How fast does the auto-switch function work?
The system features an automatic switch between DC and AC power with a transfer time of less than 5ms, ensuring uninterrupted operation for your connected devices.
Can I monitor the system remotely?
Yes, the unit comes with standard RS232 and RS485 communication ports. There is also an optional SNMP port available for network-based remote monitoring and management.
What kind of protections does this inverter offer?
It includes a comprehensive protection suite: short circuit protection, overload protection, battery over/under voltage protection, over current protection, and over temperature protection.
Is the unit suitable for standard server racks?
Absolutely. The inverter is designed with a standard 19-inch rack-mount case, making it perfect for IT infrastructure, data centers, and telecommunication rooms.
What information is displayed on the LCD?
The large 128*64 digital LCD provides real-time data on input/output voltage, frequency, output current, internal temperature, and capacity rate.
