| Input Voltage Range | 220VAC (176V-280V) |
| Input Frequency | 50/60HZ |
| Power Factor | 0.98 |
| Output Voltage | 48VDC |
| Output Voltage Range | 42V-58VDC |
| Output Current Range | 600A |
| Output Efficiency | 93% |
| Regulation | ±2% |
| Load Regulation | ±2% |
| Line Regulation | ±1 |
| Leakage Current | ≤3.5mA |
| Nominal Operating Temperature | -15~55°C |
| Operating Temperature | -33~55°C |
| Cooling Method | Forced cooling, front-in & rear-out, the fan is located inside the front panel, with programmable speed by the temperature. |
| Ingress Protection | The unit can operate when the diameter of dust particle is more than 5μm, with density ≤3*104 /m3. The dust shall not be conducting, electromagnetic or corrosive. |
