INTRODUCTION
This is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Key Features
- Pure sine wave inverter
- Inverter running without battery
- Built-in MPPT solar controller
- Configurable input voltage range via LCD setting
- Configurable battery charging current
- Configurable AC/Solar Charger priority
- Compatible to mains voltage or generator power
- Auto restart while AC is recovering
- Overload / Over temperature / Short circuit protection
- Smart battery charger design for optimized performance
- Cold start function
Specifications
|
| Input Voltage Waveform | Sinusoidal (utility or generator) |
| Nominal Input Voltage | 230Vac |
| Low Loss Voltage | 170Vac±7V (UPS); 90Vac±7V (Appliances) |
| High Loss Voltage | 280Vac±7V |
| Nominal Input Frequency | 50Hz / 60Hz (Auto detection) |
| Efficiency (Line Mode) | >95% (Rated R load, battery full charged) |
| Transfer Time | 10ms typical (UPS); 20ms typical (Appliances) |
|
| Rated Output Power | 5KVA/5KW |
| Output Voltage Waveform | Pure Sine Wave |
| Output Voltage Regulation | 230Vac±5% |
| Peak Efficiency | 94% |
| Nominal DC Input Voltage | 48Vdc |
| Surge Capacity | 2* rated power for 5 seconds |
|
| Max Charging Current (PV+AC) | 100Amp |
| Max Charging Current (AC) | 60Amp |
| Rated PV Power | 5500W |
| Max PV Open Circuit Voltage | 500Vdc |
| MPPT Voltage Range | 120Vdc~450Vdc |
|
| Safety Certification | CE |
| Operating Temperature | -10°C to 55°C |
| Dimension (D*W*H) | 438 x 438 x 130.8 mm |
| Net Weight | 14 kg |
Frequently Asked Questions
Can this inverter operate without a battery?
Yes, this inverter is designed with a special feature that allows it to run without a battery connected.
What is the maximum Solar Panel (PV) input capacity?
The unit supports a maximum PV array power of 5500W with an MPPT voltage range of 120Vdc to 450Vdc.
Is the output compatible with sensitive electronics?
Absolutely. It provides a Pure Sine Wave output, which is compatible and safe for home appliances and personal computers.
Does it support both AC and Solar charging simultaneously?
Yes, it features a built-in MPPT solar controller and can combine PV and AC charging for a maximum current of 100Amp.
What safety protections are built into the device?
The inverter includes comprehensive protection against overload, over-temperature, and short circuits, along with an auto-restart function during AC recovery.
Can I prioritize solar energy over the utility grid?
Yes, the AC/Solar charger priority is fully configurable via the LCD settings to suit your specific application needs.
